Laser Chiller 15000W
Hanli laser cooling machineHL-15000 is a reliable, efficient, and cost-effective solution for cooling high-power fiber lasers and other equipment
With its advanced features and high-performance capabilities, it can help businesses and laboratories improve their productivity, reduce downtime, and achieve better results
- Product Introduction
The HL-15000 laser cooling machine can be used in various applications, such as laser cutting, welding, engraving, and marking. Its advanced features make it suitable for both industrial and laboratory use. Its compact and ergonomic design makes it easy to install, operate, and maintain, while its low noise and vibration level ensure a quiet and stable operation.
Overall, Hanli laser cooling machineHL-15000 is a reliable, efficient, and cost-effective solution for cooling high-power fiber lasers and other equipment. With its advanced features and high-performance capabilities, it can help businesses and laboratories improve their productivity, reduce downtime, and achieve better results
for cooling large-scale laser systems. With a cooling capacity of up to 48,000 watts, it is capable of effectively dissipating the heat generated by high-power lasers, ensuring stable and reliable operation.
The HL-15000 features a compact and modular design, making it easy to install and operate. It is equipped with advanced temperature and pressure sensors, as well as a user-friendly control panel that allows for precise temperature and flow rate adjustments.
The cooling unit employs a closed-loop cooling system that uses a high-performance compressor, condenser, and evaporator to remove heat from the laser system. It also incorporates a filtration system that removes impurities and extends the lifespan of the coolant.
Overall, the Hanlilasercoolingmachine HL-15000 is a robust and efficient cooling solution for high-power laser systems, delivering superior cooling performance and reliability in demanding industrial environments.
According to customer reviews, the laserchiller15000w is reliable and easy to use, with a simple control panel and a digital display that shows temperature and other settings. It also operates quietly and efficiently, with low power consumption and minimal maintenance requirements.
Overall, the laserchiller15000w seems to be a solid choice for businesses or individuals operating high-power laser cutters or engravers that require precise temperature control for optimal performance.
|
|
|
|
Voltage & Frequency |
3p 380V/50Hz |
|
maximum current |
40.0A |
|
Rated power |
28.0kW |
|
Horsepower |
12.5hp |
|
Compressor power |
9.037kw |
|
Electric heating power |
0.8+7.2Kw |
|
Pump power |
3.0kw/0.12kw |
|
Fan power |
0.60kw×2 |
|
Maximum air volume of the fan |
8750*2m³ ./h |
|
Rated Flow of the low temperature end |
≥220L/min |
|
Rated pressure of the low temperature end |
5.0bar |
|
Maximum pressure of low temperature end |
8.4bar |
|
Dimensions of the low temperature end interface |
G1-1/2-Φ38mm Pagoda joints |
|
Water temperature setting range of low temperature end |
21-32℃ |
|
Rated Flow of the high temperature end |
4.5L/min |
|
Rated pressure of the high temperature end |
5.0bar |
|
Dimensions of the high temperature end interface |
G1/2-Φ12mm Pagoda joints |
|
Water temperature setting range of high temperature end |
26-35℃ |
|
Water temperature control accuracy |
±1℃ |
|
Water Tank |
160L |
|
Application environment |
5-40℃ |
|
Coolant |
R32 |
|
Noise Level |
≈ 75dB(A) |
|
Net Weight |
246KG |
|
Gross Weight |
257KG |
|
Machine dimension |
1620×755 × 1070 mm |
|
Packing dimension |
1690×810 × 1150 mm |
|
Suitable cooling medium |
Pure water , glycol solution(concentration ≤ 30%) |
