Co2 Laser Chiller
The HL-180-C is a power supply unit with a maximum power output of 600W that is designed to provide accurate and efficient power control. This unit is equipped with single temperature controls and can regulate flow temperatures with ease. It also includes an over-temperature alarm and thermal...
- Product Introduction
The HL-180-C is a power supply unit with a maximum power output of 600W that is designed to provide accurate and efficient power control. This unit is equipped with single temperature controls and can regulate flow temperatures with ease. It also includes an over-temperature alarm and thermal protection for its compressor, making it a reliable and safe choice for industrial applications.
In addition to its performance capabilities, the HL-130W-C is also environmentally friendly, designed to meet international environmental protection standards. It has been built with materials that are free from harmful substances, and it features a high level of energy efficiency, using minimal power to produce maximum results.
Overall, the HL-180-C is a powerful and versatile power supply unit that is designed to deliver high-quality and reliable performance in a wide range of industrial settings. Its precision controls and advanced safety features make it a top choice for businesses and organizations that require high levels of performance and safety from their power supply equipment.
|
Model |
HL-100-C |
HL-180-C |
|
Voltage & Frequency |
AC 1P 220 V |
|
|
Working power |
50Hz |
|
|
Working current |
3 A |
5.5 A |
|
Machine power |
0.6kW |
1.2 kW |
|
Application environment |
0℃＜Environment temperature＜45℃ ,Relative humidity＜95% |
|
|
Tempe.control accuracy |
±1 ℃ |
|
|
Coolant |
R32 |
R410A |
|
Cooling capacity |
900W |
1800W |
|
Electric heating power |
400W |
400W |
|
Rated flow of water pump |
16L/min |
|
|
Max.pump lift |
16 m |
|
|
Pump power |
50W |
|
|
Tank volume |
8 L |
|
|
Laser nozzle interface |
G1/2*Φ12 Quick connector |
|
|
Dimension |
592×313×517 (mm) |
|
|
N.W |
24 kg |
25 kg |
|
Packing size |
615×365×550 (mm) |
|
|
G.W |
26.5 kg |
27.5 kg |
|
Matching laser source |
100WCO2 Laser |
130-180WCO2 Laser |
