Fiber Laser Chiller Ipg Chiller
*6000W fiber laser chillers are specially used to cool 6000W fiber laser.
*Cooling capacity:18000W
*6000W Hanli Laser Chiller for Raycus Laser Source 6kw
- Product Introduction
Product Features
*6000W fiber laser chillers are specially used to cool 6000W fiber laser.
*6000W Hanli Laser Chiller for Raycus Laser Source 6kw
Hanli industrial temperature control system HL-6000 is specially designed for fiber laser processes up to 6KW. It comes with a dual refrigeration circuit and each refrigeration circuit is working independently from the other. Thanks to this brilliant circuit design, both the fiber laser and the optics can be perfectly cooled. Therefore, the laser output from the fiber laser processes can be more stable
and consistent, leading to higher quality results and longer overall lifespan of the equipment.
The HL-6000 temperature control system also features a user-friendly touch screen panel with easy-to-operate settings and controls. The system is equipped with a number of safety measures, including alarms for high and low temperatures, as well as pressure and flow rate monitoring.
Overall, the Hanli Industrial Temperature Control System HL-6000 is an excellent choice for those looking to improve the efficiency and reliability of their fiber laser processes. Its dual refrigeration circuit design ensures consistent and reliable cooling, while its advanced features and safety precautions make it a great investment for any business.
6000W Water Chiller Specification:
|
|
Uint |
HL-6000-QG2/2 |
HL-6000-EH-QG2/2 |
|
Voltage & Frequency |
1p 220V/50Hz |
1p 220V/60Hz |
|
|
Rated power |
kW |
7.6 |
7.6 |
|
maximum current |
A |
28 |
28 |
|
Cooling capacity |
kW |
19.1 |
19.1 |
|
Compressor power |
kW |
1.48×2 |
1.4×2 |
|
Electric heating power |
kW |
1.25/1.4 |
|
|
Pump power |
kW |
0.88 |
0.88 |
|
Fan power |
kW |
0.208×2 |
0.208×2 |
|
Maximum air volume of the fan |
m³/h |
3955×2 |
3955×2 |
|
Rated Flow of the low temperature end |
L/min |
60～66 |
|
|
Rated pressure of the low temperature end |
bar |
4.0 |
|
|
Maximum pressure of low temperature end |
bar |
6.0 |
|
|
Dimensions of the low temperature end interface |
G3/4-Φ25mm ,G1-Φ25mm Pagoda joints |
||
|
Water temperature setting range of low temperature end |
℃ |
21～32 |
|
|
Rated Flow of the high temperature end |
L/min |
2.0 |
|
|
Rated pressure of the high temperature end |
bar |
3.5 |
|
|
Dimensions of the high temperature end interface |
G1/2-Φ12mm quick connector |
||
|
Water temperature setting range of high temperature end |
℃ |
26～35 |
|
|
Water temperature control accuracy |
℃ |
22～29.5 |
|
|
Water Tank |
L |
55 |
|
|
Application environment |
℃ |
-20～40 |
|
|
Coolant |
R32 |
||
|
Noise Level |
dB(A) |
≈75 |
|
|
Machine dimension |
mm |
104 |
|
|
Net Weight |
kg |
1040×510×890 |
|
|
Packing dimension |
mm |
111 |
|
|
Gross Weight |
kg |
1100×570×960 |
|
|
Suitable cooling medium |
Pure water , glycol solution(concentration ≤ 30%) |
||
