Laser Chiller Unit 12kw
* Temperature stability: ±1°C
* Application environment: 0°C ~45°C
* Refrigerant: R32
* User-friendly controller interface
- Product Introduction
Product Features
The HL-12000 cooling system features a user-friendly control interface that allows for precise temperature regulation and monitoring. The system also has a built-in alarm system that alerts users to any abnormalities, ensuring that any issues are quickly addressed before they can cause downtime or damage to equipment.
The dual refrigeration circuit design of the HL-12000 ensures that if one circuit fails, the other circuit will maintain cooling, preventing damage to the fiber laser or optics. The cooling system also includes a built-in filtration system that removes impurities from the water, ensuring consistent cooling performance and protecting the laser and optics from contaminants.
Overall, the Hanli HL-12000 cooling system is a high-performance solution that offers advanced features and reliable operation. It is an ideal solution for industrial applications that require efficient and precise cooling of fiber laser equipment and optics.
|
|
HL-12000-QG2/2 |
HL-12000-EH-QG2/ |
|
Voltage & Frequency |
3p 380V/50Hz |
3p 380V/60Hz |
|
maximum current |
26.5A |
26.5A |
|
Rated power |
18.0kW |
18.0kW |
|
Horsepower |
8hp |
8hp |
|
Compressor power |
2.99kw |
6.03kw |
|
Electric heating power |
1.6+1.4Kw |
|
|
Pump power |
2.2w |
2.2kw |
|
Fan power |
0.95kw |
0.98kw |
|
Maximum air volume of the fan |
11810m³ ./h |
12130m³ ./h |
|
Rated Flow of the low temperature end |
120~132L/min |
|
|
Rated pressure of the low temperature end |
4.0bar |
|
|
Maximum pressure of low temperature end |
7.0bar |
|
|
Dimensions of the low temperature end interface |
Φ37.5×60-Φ32mm Pagoda joints |
|
|
Water temperature setting range of low temperature end |
21-32℃ |
|
|
Rated Flow of the high temperature end |
3.0L/min |
|
|
Rated pressure of the high temperature end |
4.0bar |
|
|
Dimensions of the high temperature end interface |
Φ37.5×48-Φ13mm Pagoda joints |
|
|
Water temperature setting range of high temperature end |
26-35℃ |
|
|
Water temperature control accuracy |
±1℃ |
|
|
Water Tank |
77L |
|
|
Application environment |
5-40℃ |
|
|
Coolant |
R32 |
|
|
Noise Level |
≈ 74dB(A) |
|
|
Net Weight |
145KG |
|
|
Gross Weight |
160KG |
|
|
Machine dimension |
780×760 × 1060mm |
|
|
Packing dimension |
820×810 × 1240mm |
|
|
Suitable cooling medium |
Pure water , glycol solution(concentration ≤ 30%) |
|
